truck bed specs
Each Traffic Pro Bed series refers to the size of the truck bed and the corresponding specifications a truck needs to meet in order to be compatible with a given TPB series. Currently, our Traffic Pro Bed models’ come in five different series. Those are the 200, 300, 400, 500, and 800 series. The 200 being our smallest option for midsize trucks and the 800 being the largest series we currently offer for heavy duty trucks. Every series beyond the 200 requires a dually truck.
Please refer to the specs below to determine which series is compatible with your trucks, as well as gain insight on the kind of load capacity you can expect from a given traffic pro bed. Note, the cone capacity stated is based on an estimated 12lb weight per cone. The real load capacity of a given truck may vary and is up to the truck owner and operator to verify.
For more help: contact us specifying the make, model, and year of your truck/trucks and we can assist you to determine which Traffic Pro Bed series is right for your truck.
TPB Specifications
200 Series
Cone Capacity: 100
Dimensions: 120″ L x 88″ W
Required Truck Specs: ¾ to 1 ton SRW truck with a 60″ CA
| 200 Series Weight by Model | |||
|---|---|---|---|
| Base Safety Body | Full Traffic Body | Half Stake Body | Full Stake Body |
| 964 lb. | 1,562 lb. | 1,335 lb. | 1,089 lb. |
TRUCK BED WEIGHT SPECIFICATIONS by Series
This is the weight of each Configuration by Series.
Series | Base Safety | Full Traffic | Half Stake | Full Stake |
200 | 964 lb. | 1,562 lb. | 1,335 lb. | 1,089 lb. |
300 | 1,049 lb. | 1,647 lb. | 1,415 lb. | 1,167 lb. |
400 | 1,091 lb. | 1,689 lb. | 1,475 lb. | 1,227 lb. |
500 | 1,157 lb. | 1,755 lb. | 1,640 lb. | 1,381 lb. |
800 | 1,669 lb. | 2,267 lb. | 1,981 lb. | 1,715 lb. |
TRUCK SPECIFICATIONS By Series
This is the prescribed *cone count, truck deck dimensions, and required truck specifications.
Series | *Cone Count | Dimensions | Truck Class | Truck Specs |
200 | 100 cones | 120” L x 88” W | 2 - 3 | ¾ to 1 ton SRW truck with a 60” CA |
300 | 200 cones | 120” L x 98” W | 3 - 5 | Dually truck with a 60” CA |
400 | 300 cones | 136” L x 98” W | 3 - 4 | Dually truck with a 84” CA |
500 | 400 cones | 152” L x 98” W | 5 | Dually truck with a 108” CA |
800 | 500 cones | 188” L x 98” W | 6 | Dually truck with a 127.5” CA |
Important: The prescribed cone count is based on an estimated maximum quantity of cones with a 12 lb average weight per cone. The real load/cone capacity of a given truck may vary and is up to the truck owner and operator to verify before loading. Traffic Pro Beds LLC makes no guarantee to a prescribed cone count or load-bearing capabilities of a Traffic Pro Bed. Load-bearing capabilities are exclusively dependent on the load-bearing capabilities of the truck a given Traffic Pro Bed is installed on. It is the full and exclusive responsibility of the purchaser to evaluate the load-bearing capabilities of a given vehicle before the installation and loading of a Traffic Pro Bed.
300 Series
Cone Capacity: 200
Dimensions: 120″ L x 98″ W
Required Truck Specs: Dually truck with a 60″ CA
| 300 Series Weight by Model | ||
|---|---|---|
| Full Traffic Body | Half Stake Body | Full Stake Body |
| 1,734 lb. | 1,667 lb. | 1,482 lb. |
400 Series
Cone Capacity: 300
Dimensions: 136″ L x 98″ W
Required Truck Specs: Dually truck with a 84″ CA
| 400 Series Weight by Model | ||
|---|---|---|
| Full Traffic Body | Half Stake Body | Full Stake Body |
| 1,776 lb. | 1,802 lb. | 1,623 lb. |
500 Series
Cone Capacity: 400
Dimensions: 152″ L x 98″ W
Required Truck Specs: Dually truck with a 108″ CA
| 500 Series Weight by Model | ||
|---|---|---|
| Full Traffic Body | Half Stake Body | Full Stake Body |
| 1,865 lb. | 1,919 lb. | 1,741 lb. |
The 800 Series
Contact us about our 800 series TPB specs. Our first TPB series for class 6 trucks and up.
This series provides all of TPB’s patented safety features while providing more storage and equipment mounting options including TMA and VMS board installations. Contact us for more information.
Product Literature & Disclaimers
For a printable reference to the above product specifications and full product literature please click download, please see below. Also please direct yourself to the following disclaimer on the specifications provided.
The stated cone capacity is based on an estimated maximum quantity of cones with a 12lb average weight per cone. The real load/cone capacity of a given truck may vary and is up to the truck owner and operator to verify before loading.
